Planmeca ProMax - 17 TECHNICAL SPECIFICATIONS; 17.1 Technical data for Planmeca ProMax product family

Planmeca ProMax 3D Max with ProTouch 55
TECHNICAL SPECIFICATIONS
User’s Manual
17 TECHNICAL SPECIFICATIONS
NOTE: SEE TECHNICAL MANUAL FOR USER’S STATEMENT
17.1 Technical data for Planmeca ProMax product family
Classification:
• Medical Device Directive 93/42/EEC (Class IIb)
• IEC 60601-1 Class I, type B
• CISPR 11 Class B
Generator
Resonant-mode, DSP-controlled, 80...160 kHz,
according to IEC 60601-2-7: 1998
X-ray tube
2D / 3D s / 3D Classic / 3D Plus / 3D Mid:
Toshiba D-054SB
3D Max: Toshiba D-067SB
Focal spot size
According to IEC 60336
2D / 3D s / 3D Classic / 3D Plus / 3D Mid:
0.5 x 0.5 mm
3D Max: 0.6 x 0.6 mm
Total filtration:
• 3D min. 2.5 mm Al + 0.5 mm Cu
• Pan / ceph min. 2.5 mm Al
Anode voltage
(X-ray units with SW prior to 3.0):
• 3D 3D s / 3D Classic / 3D Mid: 54 - 90 kV ±5%
3D Max: 54 - 96 kV ±5%
• Pan / SmartPan 54 - 84 kV ±5%
• Ceph 60 - 84 kV ±5%
Anode voltage
(X-ray units with SW 3.0 or later):
• 3D 3D s / 3D Classic / 3D Plus / 3D Mid:
60 - 90 kV ±5%
3D Max: 60 - 96 kV ±5%
• Pan / SmartPan 60 - 84 kV ±5%
• Ceph 60 - 84 kV ±5%
Anode current
(X-ray units with SW prior to 3.0):
• 3D 3D s / 3D Classic / 3D Mid: 1 - 14 mA ±10%
3D Max: 1 - 12.5 mA ±10%
• Pan / SmartPan 1 - 16 mA ±10%
