13.Remove the outer slip-fit post and install the Drive
Clutch Puller (PN PU-52919) and holder (PN PU-
52920) to remove the stationary sheave.
Drive Clutch Puller:
PU-52919
Drive Clutch Holder
PU-52920
14.Remove inner clutch cover fasteners
i
and
o
, and
remove the inner clutch cover.
15.Remove two O-rings
a
from the transmission.
16.Disengage hose clamps
s
and remove vent hoses
from the transmission.
17.Disconnect rear tail light harness.
18.Remove eight fasteners
d
from the rear fascia, and
two fasteners
f
from the rear bumper. Remove rear
fascia and bumper.
19.Loosen two air box hose clamps
g
and disconnect
air ducts from the air box.
