TRANSMISSION ASSEMBLY
1. Thoroughly clean the mating surfaces of the
transmission case halves so they are free of 3 Bond
sealant. Failure to properly clean the surfaces may
lead to transmission case leaks.
2. Install output shaft gear
o
.
3. Install front output shaft
i
into gear housing.
4. Install three idler gears
u
as an assembly.
5. Install transmission input shaft
y
.
6. Install the shift shaft and forks as an assembly.
7. Lift up on the shift shaft rail and move the rail
assembly rearward to allow the shift fork pins to be
installed onto the shift drum
t
. Install the shift drum
into the transmission housing.
8. Install the two sector gears.
TRANSMISSION
