20.Install ball joint pinch bolt, washer, nut. Torque
fastener to specification.
TORQUE
Upper Ball Joint Pinch Bolt:
52 ft-lbs (70 Nm) - Torque bolt side
21.Install front fascia and four front fascia mounting
fasteners.
TORQUE
Front Fascia Fasteners:
7 ft-lbs (10 Nm)
FRONT PROP SHAFT REPLACEMENT
REMOVAL
1. Place vehicle on a suitable lift or jack and remove
front wheel.
2. Remove four front fascia fasteners
q
and remove
front fascia.
3. Both sides of vehicle: Remove ball joint pinch bolt
w
,
washer, and nut from the upper control arms.
4. Driver’s side only: Remove two control arm mounting
fasteners
e
.
IMPORTANT
The access panel must be removed from the driver’s
side footwell to remove rear upper control arm fastener.
