Polaris RZR Pro R 2022 Service Manual

9
9940259 R02 - 2022 RZR PRO R / PRO R 4 Service Manual
© Copyright Polaris Industries Inc.
9.27
REAR STABILIZER BAR REPLACEMENT
REMOVAL
1. Lift and support vehicle by main frame.
2. Remove rear wheel nuts and wheels.
3. Mark orientation of stabilizer bar arm onto the
stabilizer bar to ensure correct orientation upon
installation.
4. Remove the fasteners retaining the stabilizer bar to
the linkage
q
on each side of the vehicle.
5. Remove the four fasteners
w
retaining the stabilizer
bar to the vehicle frame.
6. Remove the bushing brackets and bushings for ease
of removal.
7. Carefully remove the stabilizer from the LH wheel well
area of the vehicle.
8. Inspect the stabilizer bar for straightness. Inspect the
pivot bushings and replace if needed.
INSTALLATION
1. Carefully install stabilizer bar through the LH wheel
well area.
2. Fully install stabilizer bar, bushings, bracket and
bracket fasteners and stabilizer links. Center
stabilizer bar in the frame. Torque fasteners to
specification (see below).
3. Torque all fasteners to specification (see below).
4. Lubricate stabilizer bar pivot bushings via grease
fitting.
5. Install rear wheels and wheel nuts. Torque wheel nuts
to specification.
TORQUE
Rear Stabilizer Bar Linkage:
81 ft-lbs (110 Nm)
Stabilizer Bar Mounting Bracket Bolts:
52 ft-lbs (70 Nm)
Wheel Lug Nuts:
148 ft-lbs (200 Nm)
STEERING / SUSPENSION
