ELECTRICAL COMPONENT LOCATIONS (FRONT)
k
Headlight Switch
2%
12V Receptacle
l
AWD Switch
2^
PULSE Bar
1(
C4 Gauge
2&
EPS Power
2)
Key Switch
2*
EPS Signal
2!
Diagnostic Plug
2(
Speaker
2@
Drive Mode Switch
3)
Ambient Air Temperature Sensor
2#
Ride Command Display
3!
Headlight
2$
Fuse Block
3@
Accent Light
ELECTRICAL
