Polaris RZR Pro R 2022

12
9940259 R02 - 2022 RZR PRO R / PRO R 4 Service Manual
© Copyright Polaris Industries Inc.
12.5
ELECTRICAL COMPONENT LOCATIONS (REAR)
q
Tail Light Harness
o
Starter (+)
w
Back Up Camera
a
ECU Harness
e
Rear Box Harness
s
Engine Harness
r
Oxygen Sensor
d
Transmission Harness
t
Fuel Injector
f
Fuse Box
y
Alternator Harness
g
12V receptacle
u
Alternator (+)
h
Battery Negative (-)
i
Coolant Temperature Sensor
j
Battery Positive (+)
ELECTRICAL
