3
9940259 R02 - 2022 RZR PRO R / PRO R 4 Service Manual
© Copyright Polaris Industries Inc.
3.75
5. Install breather assembly, and gasket to the engine
block. Torque four fasteners in sequence to
specification.
TORQUE
Engine Breather Fasteners:
80 in-lbs (9 N·m)
6. Install the piston jets.
IMPORTANT
Lubricate the o-rings with engine oil. Ensure the piston
jets are seated prior to torquing fasteners
7. Install the piston jet fasteners and torque to
specification.
TORQUE
Piston Jet Fasteners:
89 in-lbs (10 N·m)
ENGINE / COOLING SYSTEM
