10.Install gear position sensor shield and four fasteners
2!
. Torque fasteners to specification as shown.
TORQUE
Gear Position Sensor Shield Fasteners:
qq
: 15 ft-lbs (20 Nm)
ww
: 22 ft-lbs (30 Nm)
ee
: 72 in-lbs
(8 Nm)
11. Install exhaust pipe onto engine. Install nine fasteners
2)
. Torque fasteners to specification in the sequence
shown.
NOTICE
Exhaust headpipe hidden for image clarity
TORQUE
Exhaust Headpipe Fasteners:
Step 1: 60 in-lbs (7 Nm)Step 2: 22 ft-lbs (30 Nm)
12.Connect oxygen sensor electrical harness.
TRANSMISSION
