8.24
9940259 R02 - 2022 RZR PRO R / PRO R 4 Service Manual
© Copyright Polaris Industries Inc.
14.Install control arm into its inner mounts, and ball joint
into the bearing carrier.
15.Install two control arm mounting fasteners. Torque
fasteners to specification.
TORQUE
Control Arm Mounting Fasteners:
133 ft-lbs (180 Nm) - Torque bolt side
16.Install ball joint pinch bolt, washer, nut. Torque
fastener to specification.
TORQUE
Upper Ball Joint Pinch Bolt:
52 ft-lbs (70 Nm) - Torque bolt side
17.Install front fascia and four front fascia mounting
fasteners.
TORQUE
Front Fascia Fasteners:
7 ft-lbs (10 Nm)
FINAL DRIVE
