9940259 R02 - 2022 RZR PRO R / PRO R 4 Service Manual
© Copyright Polaris Industries Inc.
RZR PRO R REAR SHOCK VALVING
CHECK VALVE COMPRESSION REBOUND CLICKER ASSEMBLY
1.55 x 0.008 1.750 x 0.140 1.85 x 0.008 0.700 x 0.010
1.00 x 0.008 1.10 x 0.015 1.85 x 0.008 CLICKER PISTON
0.900 x 0.060
(round side to shim)
1.20 x 0.015 1.00 x 0.012 1.000 x 0.012
1.30 x 0.010 1.65 x 0.008 1.000 x 0.012
1.45 x 0.010 1.55 x 0.012 0.700 x 0.012
1.55 x 0.010 1.45 x 0.012 0.600 x 0.015
1.65 x 0.010 1.30 x 0.010 0.600 x 0.015
1.75 x 0.010 1.30 x 0.010
1.90 x 0.010 1.10 x 0.015
2.05 x 0.012 0.900 x 0.008
1.20 x 0.015
0.900 x 0.060
No Piston Bleed Orifice
RZR PRO R 4 REAR SHOCK VALVING
CHECK VALVE COMPRESSION REBOUND CLICKER ASSEMBLY
1.55 x 0.008 1.750 x 0.140 1.85 x 0.008 0.700 x 0.010
1.10 x 0.008 1.00 x 0.010 1.85 x 0.008 CLICKER PISTON
0.900 x 0.060 1.10 x 0.010 1.10 x 0.012 1.000 x 0.015
1.20 x 0.010 1.65 x 0.012 1.000 x 0.015
130 x 0.010 1.55 x 0.012 0.900 x 0.015
1.45 x 0.012 1.45 x 0.012 0.600 x 0.015
1.55 x 0.012 1.30 x 0.012 0.600 x 0.015
1.65 x 0.012 1.20 x 0.012
1.75 x 0.012 1.10 x 0.015
1.85 x 0.012 1.00 x 0.015
1.90 x 0.010 1.30 x 0.015
2.05 x 0.008 0.900 x 0.060
2.05 x 0.008
2.05 x 0.008
No Piston Bleed Orifice
STEERING / SUSPENSION
