9940259 R02 - 2022 RZR PRO R / PRO R 4 Service Manual
© Copyright Polaris Industries Inc.
SPN COMPONENT
FMI CONDITION CODE
563 ABS active
19 Received Network Data In Error U25C9
597 Brake Switch
2 Data Erratic, Intermittent Or Incorrect C0040
9 Abnormal Update Rate C1240
10 Abnormal Rate Of Change C2453
19 Received Network Data In Error C1340
627
System Voltage
15 Data Valid But Above Normal Operating Range - Least Severe Level P2504
17 Data Valid But Below Normal Operating Range - Least Severe Level P2503
628
ECU Memory
12 Bad Intelligent Device Or Component P1602 / C1073
13 Out Of Calibration P0601 / C1601
630 Calibration 19 Checksum/CRC Error C1074
634 Idle Air Control
3 Voltage Above Normal, Or Shorted To High Source P0509
4 Voltage Below Normal, Or Shorted To Low Source P0508
5 Current Below Normal Or Open Circuit P0505
7 Mechanical System Not Responding Or Out Of Adjustment P0519
13 Out Of Calibration P1300
636 Crankshaft Position Sensor
2 Plausibility Fault P0335
8 Abnormal Frequency Or Pulse Width Or Period P0336
637 Camshaft Position Sensor
7 Mechanical System Not Responding Or Out Of Adjustment P0016
8 Abnormal Frequency Or Pulse Width Or Period P0340
645 Tachometer Driver Circuit
3 Voltage Above Normal, Or Shorted To High Source P1739
4 Voltage Below Normal, Or Shorted To Low Source P1738
5 Current Below Normal Or Open Circuit P1737
651
Injector 1 (MAG)
4 Voltage Below Normal / Shorted To Low Source / Driver Circuit
Grounded.
P1262
5 Current Below Normal / Open Circuit / Driver Circuit Open / Grounded P0261
652
Injector 2 (PTO)
3 Voltage Above Normal, Or Shorted To High Source / Driver Circuit Short
to B+
P0265
4 Voltage Below Normal, Or Shorted To Low Source / Driver Circuit
Grounded
P1265
5 Current Below Normal Or Open Circuit / Driver Circuit Open / Grounded P0264
677 Starter Solenoid Driver Circuit
3 Voltage Above Normal, Or Shorted To High Source P0617
4 Voltage Below Normal, Or Shorted To Low Source P0616
5 Current Below Normal Or Open Circuit P0615
731 Knock Sensor 1
1 Data Valid But Below Normal Operational Range - Most Severe Level P0326
2 Data Erratic, Intermittent Or Incorrect P0325
3 Voltage Above Normal, Or Shorted To High Source P0328
4 Voltage Below Normal, Or Shorted To Low Source P0327
746
Rear Differential Output (Turf)
3 Driver Circuit Short to B+ P1692
4 Driver Circuit Grounded P1693
5 Driver Circuit Open / Grounded P1691
876
AC Compressor Clutch Relay
3 Voltage Above Normal, Or Shorted To High Source P0647
4 Voltage Below Normal, Or Shorted To Low Source P0646
5 Current Below Normal Or Open Circuit P0645
GENERAL INFORMATION
