12
9940259 R02 - 2022 RZR PRO R / PRO R 4 Service Manual
© Copyright Polaris Industries Inc.
12.39
LABEL
VALUE
FUNCTION
EFI 10A Fuse Accessory Relay Coil,
ECM Wake-Up, Pump
Relay Coil, Chassis
Relay Coil, Start Relay
Coil, EFI Relay Coil,
Injectors, SCM Relay
Coil (optional), Lights
Relay Coil, Ignition
Coil, Starter Solenoid
Coil, Brake Relay Coil
COIL
7.5A Fuse Ignition coils
FRONT DIFF 10A Fuse Front Differential
CHARGE
15A Fuse
Battery Charge Port
Additional Fuses (if equipped)
SCM 10A Fuse Shock Control Module
SHOCK
15A Fuse
Shock Power
ELECTRICAL
