1.44
9940259 R02 - 2022 RZR PRO R / PRO R 4 Service Manual
© Copyright Polaris Industries Inc.
SPN COMPONENT
FMI CONDITION CODE
5 Current Below Normal Or Open Circuit P107E
520498 Stator
4 Voltage Below Normal, Or Shorted To Low Source P1510
5 Current Below Normal Or Open Circuit P1511
520513 Motor Controller Encoder
2 Data Erratic, Intermittent Or Incorrect P1140 / P1368
31 Condition Exists P1141 / P1369
520514
Motor Controller Temperature
Sensor
3 Voltage Above Normal, Or Shorted To High Source P1142 / P1165
4 Voltage Below Normal, Or Shorted To Low Source P1143 / P1166
31 Condition Exists P1144 / P1167
520515
Electric Motor Temperature
0 Data Valid But Above Normal Operational Range - Most Severe Level P1145 / P1168
4 Voltage Below Normal, Or Shorted To Low Source P1B0D / P1169
520516
Motor Controller Temperature
0 Data Valid But Above Normal Operational Range - Most Severe Level P1146 / P116A
520517 Motor Controller
3 Voltage Above Normal, Or Shorted To High Source P1147 / P1184
6 Current Above Normal Or Grounded Circuit P1148 / P1185
12 Bad Intelligent Device Or Component P1149 / P1186
19 Received Network Data In Error P1150 / P1187
520518 Motor Controller Contactor
5 Current Below Normal Or Open Circuit P1151 / P1177
6 Current Above Normal Or Grounded Circuit P1152 / P1178
520519
Motor Controller Speed Sensor
31 Condition Exists P1153 / P116B
520520 BMC CAN Communication
31 Condition Exists P0754
520522
Display Relay
5 Current Below Normal Or Open Circuit P3038
524067 Drive Mode Select Switch
2 Data Erratic, Intermittent Or Incorrect P153C
3 Voltage Above Normal, Or Shorted To High Source P153A
4 Voltage Below Normal, Or Shorted To Low Source P153B
524070
Operator Presence Switch
3 Voltage Above Normal, Or Shorted To High Source P251C
524075
Hydraulic Oil Pressure Sensor/
Switch
17 Data Valid But Below Normal Operating Range - Least Severe Level P150F
524076
Engine Oil Pressure Sensor/Switch
17 Data Valid But Below Normal Operating Range - Least Severe Level P151F
524085
EPS Fault Lamp Driver Circuit
12 Bad Intelligent Device Or Component C106C
524086
EPS SEPIC Voltage Error
3 Voltage Above Normal, Or Shorted To High Source C106D
4 Voltage Below Normal, Or Shorted To Low Source C106E
GENERAL INFORMATION
