49
User Setup
7.3.3 Test
7.4 RS485
Test all the analog outputs.
Adjust the current VALUE.
This value is then forced on all analog outputs and can be
verified with the use of a multimeter connected to the
analyzer.
This option allows you to adjust the communication
parameters of the analyzer. The communication protocol is
MODBUS-JBUS.
Description
NO Transmitter number (0 - 33)
BAUD Transmission speed in bauds (300, 600 1200, 2400, 4800, 9600)
PARITY Odd, even, no
STOP BIT 1 or 2
SWAP WORD Lets you reverse the send order of the data
