Table AB MODBUS Memory Map (cont.)
Register Name
Read /
Write
Register
Type
Description Default
Range,
format:
UOM Register #
Modbus
Oset #
Interpretation
Alarm Slot 1 - 30100 to 30117
Alarm Type R Input Alarm Type 0 0, 1, 2 N/A 30100 101
0 = Disabled, 1 = Absolute Temperature
2 = Absolute Current
Latching R Input Latching Alarm 0 0, 1 N/A 30101 102 0 = Non-Latching, 1 = Latching
Warning Threshold On R Input Threshold to enter warning condition N/A 0 - 65535 N/A 30102 103 Depends on alarm type
Warning Threshold O R Input Threshold to leave warning condition N/A 0 - 65535 N/A 30103 104 Depends on alarm type
Alarm Threshold On R Input Threshold to enter alarm condition N/A 0 - 65535 N/A 30104 105 Depends on alarm type
Alarm Threshold O R Input Threshold to leave alarm condition N/A 0 - 65535 N/A 30105 106 Depends on alarm type
Source Channel Low R Input Low word of source channels bit-mask, bits 0 - 15 N/A 0 - 65535 N/A 30106 107
Source Channel Mid 1 R Input Source channels bit-mask, bits 16 - 31 N/A 0 - 65535 N/A 30107 108
Source Channel Mid 2 R Input Source channels bit-mask, bits 32 - 47 N/A 0 - 65535 N/A 30108 109
Source Channel High R Input High word of source channels bit-mask, bits 48 - 63 N/A 0 - 65535 N/A 30109 110
Warning Channel Low R Input
Bit-mask of source channels in warning condition
Bits 0 - 15
N/A 0 - 65535 N/A 30110 111
Warning Channel Mid 1 R Input
Bit-mask of source channels in warning condition
Bits 16 - 31
N/A 0 - 65535 N/A 30111 112
Warning Channel Mid 2 R Input
Bit-mask of source channels in warning condition
Bits 32 - 47
N/A 0 - 65535 N/A 30112 113
Warning Channel High R Input
Bit-mask of source channels in warning condition
Bits 48 - 63
N/A 0 - 65535 N/A 30113 114
Alarm Channel Low R Input
Bit-mask of source channels in alarm condition
Bits 0 - 15
N/A 0 - 65535 N/A 30114 115
Alarm Channel Mid 1 R Input
Bit-mask of source channels in alarm condition
Bits 16 - 31
N/A 0 - 65535 N/A 30115 116
Alarm Channel Mid 2 R Input
Bit-mask of source channels in alarm condition
Bits 32 - 47
N/A 0 - 65535 N/A 30116 117
Alarm Channel High R Input
Bit-mask of source channels in alarm condition
Bits 48 - 63
N/A 0 - 65535 N/A 30117 118
Alarm Slot 2 - 30120 to 30137
Alarm Type R Input Alarm Type 0 0, 2, 1 N/A 30120 121
0 = Disabled, 1 = Absolute Temperature,
2 = Absolute Current
Latching R Input Latching Alarm 0 0, 1 N/A 30121 122 0 = Non-Latching, 1 = Latching
Warning Threshold On R Input Threshold to enter warning condition N/A 0 - 65535 N/A 30122 123 Depends on alarm type
Warning Threshold O R Input Threshold to leave warning condition N/A 0 - 65535 N/A 30123 124 Depends on alarm type
Alarm Threshold On R Input Threshold to enter alarm condition N/A 0 - 65535 N/A 30124 125 Depends on alarm type
Alarm Threshold O R Input Threshold to leave alarm condition N/A 0 - 65535 N/A 30125 126 Depends on alarm type
Source Channel Low R Input
Low word of source channels bit-mask
Bits 0 - 15
N/A 0 - 65535 N/A 30126 127
Source Channel Mid 1 R Input
Source channels bit-mask
Bits 16 - 31
N/A 0 - 65535 N/A 30127 128
Source Channel Mid 2 R Input
Source channels bit-mask
Bits 32 - 47
N/A 0 - 65535 N/A 30128 129
Source Channel High R Input
High word of source channels bit-mask
Bits 48 - 63
N/A 0 - 65535 N/A 30129 130
Warning Channel Low R Input
Bit-mask or source channels in warning condition
Bits 0 - 15
N/A 0 - 65535 N/A 30130 131
Warning Channel Mid 1 R Input
Bit-mask or source channels in warning condition
Bits 16 - 31
N/A 0 - 65535 N/A 30131 132
Warning Channel Mid 2 R Input
Bit-mask or source channels in warning condition
Bits 32 - 47
N/A 0 - 65535 N/A 30132 133
Warning Channel High R Input
Bit-mask or source channels in warning condition
Bits 48 - 63
N/A 0 - 65535 N/A 30133 134
Alarm Channel Low R Input
Bit-mask of source channels in alarm condition
Bits 0 - 15
N/A 0 - 65535 N/A 30134 135
Alarm Channel Mid 1 R Input
Bit-mask of source channels in alarm condition
Bits 16 - 31
N/A 0 - 65535 N/A 30135 136
Alarm Channel Mid 2 R Input
Bit-mask of source channels in alarm condition
Bits 32 - 47
N/A 0 - 65535 N/A 30136 137
Alarm Channel High R Input
Bit-mask of source channels in alarm condition
Bits 48 - 63
N/A 0 - 65535 N/A 30137 138
