Powell BriteSpot Plus - Table AB MODBUS Memory Map (Cont.)

Powered by Safety
®
58
Appendix D
01.4IB.48041
BriteSpot® Plus
Table AB MODBUS Memory Map (cont.)
Register Name
Read /
Write
Register
Type
Description Default
Range,
format:
UOM Register #
Modbus
Oset #
Interpretation
BriteSpot® Serial Numbers - 30300 to 30311
L S/N BS 1 R Input Low Word of Serial Number for BS1 N/A 0 - 65535 N/A 30300 301
H S/N BS 1 R Input High Word for Serial Number for BS1 N/A 0 - 65535 N/A 30301 302
L S/N BS 2 R Input Low Word of Serial Number for BS2 N/A 0 - 65535 N/A 30302 303
H S/N BS 2 R Input High Word for Serial Number for BS2 N/A 0 - 65535 N/A 30303 304
L S/N BS 3 R Input Low Word of Serial Number for BS3 N/A 0 - 65535 N/A 30304 305
H S/N BS 3 R Input High Word for Serial Number for BS3 N/A 0 - 65535 N/A 30305 306
L S/N BS 4 R Input Low Word of Serial Number for BS4 N/A 0 - 65535 N/A 30306 307
H S/N BS 4 R Input High Word for Serial Number for BS4 N/A 0 - 65535 N/A 30307 308
L S/N BS 5 R Input Low Word of Serial Number for BS5 N/A 0 - 65535 N/A 30308 309
H S/N BS 5 R Input High Word for Serial Number for BS5 N/A 0 - 65535 N/A 30309 310
L S/N BS 6 R Input Low Word of Serial Number for BS6 N/A 0 - 65535 N/A 30310 311
H S/N BS 6 R Input High Word for Serial Number for BS6 N/A 0 - 65535 N/A 30311 312
BriteSpot® Status Registers - 30312 to 30329
Status 1 R Input Status of Ch 1 N/A
0x0000
- 0x000F,
7FFF
N/A 30312 313
0 - The Channel is good
1 - Optical probe not detected
2 - Optical signal too weak
4 - Temperature out of range
8 - BriteSpot module is still initializing
0x7FFF - BriteSpot module error
Status 2 R Input Status of Ch 2 N/A
0x0000
- 0x000F,
7FFF
N/A 30313 314
Status 3 R Input Status of Ch 3 N/A
0x0000
- 0x000F,
7FFF
N/A 30314 315
Status 4 R Input Status of Ch 4 N/A
0x0000
- 0x000F,
7FFF
N/A 30315 316
Status 5 R Input Status of Ch 5 N/A
0x0000
- 0x000F,
7FFF
N/A 30316 317
Status 6 R Input Status of Ch 6 N/A
0x0000
- 0x000F,
7FFF
N/A 30317 318
Status 7 R Input Status of Ch 7 N/A
0x0000
- 0x000F,
7FFF
N/A 30318 319
Status 8 R Input Status of Ch 8 N/A
0x0000
- 0x000F,
7FFF
N/A 30319 320
Status 9 R Input Status of Ch N/A
0x0000
- 0x000F,
7FFF
N/A 30320 321
Status 10 R Input Status of Ch 10 N/A
0x0000
- 0x000F,
7FFF
N/A 30321 322
Status 11 R Input Status of Ch 11 N/A
0x0000
- 0x000F,
7FFF
N/A 30322 323
Status 12 R Input Status of Ch 12 N/A
0x0000
- 0x000F,
7FFF
N/A 30323 324
Status 13 R Input Status of Ch 13 N/A
0x0000
- 0x000F,
7FFF
N/A 30324 325
Status 14 R Input Status of Ch 14 N/A
0x0000
- 0x000F,
7FFF
N/A 30325 326
Status 15 R Input Status of Ch 15 N/A
0x0000
- 0x000F,
7FFF
N/A 30326 327
Status 16 R Input Status of Ch 16 N/A
0x0000
- 0x000F,
7FFF
N/A 30327 328
Status 17 R Input Status of Ch 17 N/A
0x0000
- 0x000F,
7FFF
N/A 30328 329
Status 18 R Input Status of Ch 18 N/A
0x0000
- 0x000F,
7FFF
N/A 30329 330
