Table AB MODBUS Memory Map (cont.)
Register Name
Read /
Write
Register
Type
Description Default
Range,
format:
UOM Register #
Modbus
Oset #
Interpretation
Alarm Slot 5 - 30140 to 30157
Alarm Type R Input Alarm Type 0 0, 1, 2 N/A 30180 181
0 = Disabled, 1 = Absolute Temperature
2 = Absolute Current
Latching R Input Latching Alarm 0 0, 1 N/A 30181 182 0 = Non-Latching, 1 = Latching
Warning Threshold On R Input Threshold to enter warning condition N/A 0 - 65535 N/A 30182 183 Depends on alarm type
Warning Threshold O R Input Threshold to leave warning condition N/A 0 - 65535 N/A 30183 184 Depends on alarm type
Alarm Threshold On R Input Threshold to enter alarm condition N/A 0 - 65535 N/A 30184 185 Depends on alarm type
Alarm Threshold O R Input Threshold to leave alarm condition N/A 0 - 65535 N/A 30185 186 Depends on alarm type
Source Channel Low R Input Low word of source channels bit-mask, bits 0 - 15 N/A 0 - 65535 N/A 30186 187
Source Channel Mid 1 R Input Source channels bit-mask, bits 16 - 31 N/A 0 - 65535 N/A 30187 188
Source Channel Mid 2 R Input Source channels bit-mask, bits 32 - 47 N/A 0 - 65535 N/A 30188 189
Source Channel High R Input High word of source channels bit-mask, bits 48 - 63 N/A 0 - 65535 N/A 30189 190
Warning Channel Low R Input
Bit-mask of source channels in warning condition
Bits 0 - 15
N/A 0 - 65535 N/A 30190 191
Warning Channel Mid 1 R Input
Bit-mask of source channels in warning condition
Bits 16 - 31
N/A 0 - 65535 N/A 30191 192
Warning Channel Mid 2 R Input
Bit-mask of source channels in warning condition
Bits 32 - 47
N/A 0 - 65535 N/A 30192 193
Warning Channel High R Input
Bit-mask of source channels in warning condition
Bits 48 - 63
N/A 0 - 65535 N/A 30193 194
Alarm Channel Low R Input
Bit-mask of source channels in alarm condition
Bits 0 - 15
N/A 0 - 65535 N/A 30194 195
Alarm Channel Mid 1 R Input
Bit-mask of source channels in alarm condition
Bits 16 - 31
N/A 0 - 65535 N/A 30195 196
Alarm Channel Mid 2 R Input
Bit-mask of source channels in alarm condition
Bits 32 - 47
N/A 0 - 65535 N/A 30196 197
Alarm Channel High R Input
Bit-mask of source channel in alarm condition
Bits 48 - 63
N/A 0 - 65535 N/A 30197 198
Alarm Slot 6 - 30200 to 30217
Alarm Type R Input Alarm Type 0 0, 1, 2 N/A 30200 201
0 = Disabled, 1 = Absolute Temperature
2 = Absolute Current
Latching R Input Latching Alarm 0 0, 1 N/A 30201 202 0 = Non-Latching, 1 = Latching
Warning Threshold On R Input Threshold to enter warning condition N/A 0 - 65535 N/A 30202 203 Depends on alarm type
Warning Threshold O R Input Threshold to leave warning condition N/A 0 - 65535 N/A 30203 204 Depends on alarm type
Alarm Threshold On R Input Threshold to enter alarm condition N/A 0 - 65535 N/A 30204 205 Depends on alarm type
Alarm Threshold O R Input Threshold to leave alarm condition N/A 0 - 65535 N/A 30205 206 Depends on alarm type
Source Channel Low R Input Low word of source channels bit-mask, bits 0 - 15 N/A 0 - 65535 N/A 30206 207
Source Channel Mid 1 R Input Source channels bit-mask, bits 16 - 31 N/A 0 - 65535 N/A 30207 208
Source Channel Mid 2 R Input Source channels bit-mask, bits 32 - 47 N/A 0 - 65535 N/A 30208 209
Source Channel High R Input High word of source channels bit-mask, bits 48 - 63 N/A 0 - 65535 N/A 30209 210
Warning Channel Low R Input
Bit-mask of source channels in warning condition
Bits 0 - 15
N/A 0 - 65535 N/A 30210 211
Warning Channel Mid 1 R Input
Bit-mask of source channels in warning condition
Bits 16 - 31
N/A 0 - 65535 N/A 30211 212
Warning Channel Mid 2 R Input
Bit-mask of source channels in warning condition
Bits 32 - 47
N/A 0 - 65535 N/A 30212 213
Warning Channel High R Input
Bit-mask of source channels in warning condition
Bits 48 - 63
N/A 0 - 65535 N/A 30213 214
Alarm Channel Low R Input
Bit-mask of source channels in alarm condition
Bits 0 - 15
N/A 0 - 65535 N/A 30214 215
Alarm Channel Mid 1 R Input
Bit-mask of source channels in alarm condition
Bits 16 - 31
N/A 0 - 65535 N/A 30215 216
Alarm Channel Mid 2 R Input
Bit-mask of source channels in alarm condition
Bits 32 - 47
N/A 0 - 65535 N/A 30216 217
Alarm Channel High R Input
Bit-mask of source channel in alarm condition
Bits 48 - 63
N/A 0 - 65535 N/A 30217 218
