Table AB MODBUS Memory Map (cont.)
Register Name
Read /
Write
Register
Type
Description Default
Range,
format:
UOM Register #
Modbus
Oset #
Interpretation
Alarm Slot 7 - 30220 to 30237
Alarm Type R Input Alarm Type 0 0, 1, 2 N/A 30220 221
0 = Disabled, 1 = Absolute Temperature
2 = Absolute Current
Latching R Input Latching Alarm 0 0, 1 N/A 30221 222 0 = Non-Latching, 1 = Latching
Warning Threshold On R Input Threshold to enter warning condition N/A 0 - 65535 N/A 30222 223 Depends on alarm type
Warning Threshold O R Input Threshold to leave warning condition N/A 0 - 65535 N/A 30223 224 Depends on alarm type
Alarm Threshold On R Input Threshold to enter alarm condition N/A 0 - 65535 N/A 30224 225 Depends on alarm type
Alarm Threshold O R Input Threshold to leave alarm condition N/A 0 - 65535 N/A 30225 226 Depends on alarm type
Source Channel Low R Input Low word of source channels bit-mask, bits 0 - 15 N/A 0 - 65535 N/A 30226 227
Source Channel Mid 1 R Input Source channels bit-mask, bits 16 - 31 N/A 0 - 65535 N/A 30227 228
Source Channel Mid 2 R Input Source channels bit-mask, bits 32 - 47 N/A 0 - 65535 N/A 30228 229
Source Channel High R Input High word of source channels bit-mask, bits 48 - 63 N/A 0 - 65535 N/A 30229 230
Warning Channel Low R Input
Bit-mask of source channels in warning condition
Bits 0 - 15
N/A 0 - 65535 N/A 30230 231
Warning Channel Mid 1 R Input
Bit-mask of source channels in warning condition
Bits 16 - 31
N/A 0 - 65535 N/A 30231 232
Warning Channel Mid 2 R Input
Bit-mask of source channels in warning condition
Bits 32 - 47
N/A 0 - 65535 N/A 30232 233
Warning Channel High R Input
Bit-mask of source channels in warning condition
Bits 48 - 63
N/A 0 - 65535 N/A 30233 234
Alarm Channel Low R Input
Bit-mask of source channels in alarm condition
Bits 0 - 15
N/A 0 - 65535 N/A 30234 235
Alarm Channel Mid 1 R Input
Bit-mask of source channels in alarm condition
Bits 16 - 31
N/A 0 - 65535 N/A 30235 236
Alarm Channel Mid 2 R Input
Bit-mask of source channels in alarm condition
Bits 32 - 47
N/A 0 - 65535 N/A 30236 237
Alarm Channel High R Input
Bit-mask of source channel in alarm condition
Bits 48 - 63
N/A 0 - 65535 N/A 30237 238
Alarm Slot 8 - 30240 to 30257
Alarm Type R Input Alarm Type 0 0, 1, 2 N/A 30240 241
0 = Disabled, 1 = Absolute Temperature
2 = Absolute Current
Latching R Input Latching Alarm 0 0, 1 N/A 30241 242 0 = Non-Latching, 1 = Latching
Warning Threshold On R Input Threshold to enter warning condition N/A 0 - 65535 N/A 30242 243 Depends on alarm type
Warning Threshold O R Input Threshold to leave warning condition N/A 0 - 65535 N/A 30243 244 Depends on alarm type
Alarm Threshold On R Input Threshold to enter alarm condition N/A 0 - 65535 N/A 30244 245 Depends on alarm type
Alarm Threshold O R Input Threshold to leave alarm condition N/A 0 - 65535 N/A 30245 246 Depends on alarm type
Source Channel Low R Input Low word of source channels bit-mask, bits 0 - 15 N/A 0 - 65535 N/A 30246 247
Source Channel Mid 1 R Input Source channels bit-mask, bits 16 - 31 N/A 0 - 65535 N/A 30247 248
Source Channel Mid 2 R Input Source channels bit-mask, bits 32 - 47 N/A 0 - 65535 N/A 30248 249
Source Channel High R Input High word of source channels bit-mask, bits 48 - 63 N/A 0 - 65535 N/A 30249 250
Warning Channel Low R Input
Bit-mask of source channels in warning condition
Bits 0 - 15
N/A 0 - 65535 N/A 30250 251
Warning Channel Mid 1 R Input
Bit-mask of source channels in warning condition
Bits 16 - 31
N/A 0 - 65535 N/A 30251 252
Warning Channel Mid 2 R Input
Bit-mask of source channels in warning condition
Bits 32 - 47
N/A 0 - 65535 N/A 30252 253
Warning Channel High R Input
Bit-mask of source channels in warning condition
Bits 48 - 63
N/A 0 - 65535 N/A 30253 254
Alarm Channel Low R Input
Bit-mask of source channels in alarm condition
Bits 0 - 15
N/A 0 - 65535 N/A 30254 255
Alarm Channel Mid 1 R Input
Bit-mask of source channels in alarm condition
Bits 16 - 31
N/A 0 - 65535 N/A 30255 256
Alarm Channel Mid 2 R Input
Bit-mask of source channels in alarm condition
Bits 32 - 47
N/A 0 - 65535 N/A 30256 257
Alarm Channel High R Input
Bit-mask of source channel in alarm condition
Bits 48 - 63
N/A 0 - 65535 N/A 30257 258
