Table AB MODBUS Memory Map (cont.)
Register Name
Read /
Write
Register
Type
Description Default
Range,
format:
UOM Register #
Modbus
Oset #
Interpretation
Modbus Current Sensor (MCS4) - 30530 to 30538
Serial Number Low Word R Input MCS Serial Number Low N/A 0 - 65535 N/A 30530 531
Serial Number High Word R Input MCS Serial Number High N/A 0 - 65535 N/A 30531 532
HW Part R Input MCS HW Part Number 10204 0 - 65535 N/A 30532 533
FW Rev R Input MCS Firmware Revision N/A 0 - 65535 N/A 30533 534
CT Secondary R Input Current Transformer Secondary Turns N/A 0 - 65535 N/A 30534 535
CT Primary R Input Current Transformer Primary Turns 1 0 - 65535 N/A 30535 536
RMS Current mA R Input Secondary RMS Current N/A 0 - 20000 mA 30536 537
RMS Current Primary R Input Primary RMS Current N/A 0 - 400 A 30537 538
Temperature R Input Unit Temperature N/A -40 - 80 °C °C / °F 30538 539
Modbus Current Sensor (MCS5) - 30540 to 30548
Serial Number Low Word R Input MCS Serial Number Low N/A 0 - 65535 N/A 30540 541
Serial Number High Word R Input MCS Serial Number High N/A 0 - 65535 N/A 30541 542
HW Part R Input MCS HW Part Number 10204 0 - 65535 N/A 30542 543
FW Rev R Input MCS Firmware Revision N/A 0 - 65535 N/A 30543 544
CT Secondary R Input Current Transformer Secondary Turns N/A 0 - 65535 N/A 30544 545
CT Primary R Input Current Transformer Primary Turns 1 0 - 65535 N/A 30545 546
RMS Current mA R Input Secondary RMS Current N/A 0 - 20000 mA 30546 547
RMS Current Primary R Input Primary RMS Current N/A 0 - 400 A 30547 548
Temperature R Input Unit Temperature N/A -40 - 80 °C °C / °F 30548 549
Modbus Current Sensor (MCS6) - 30550 to 30558
Serial Number Low Word R Input MCS Serial Number Low N/A 0 - 65535 N/A 30550 551
Serial Number High Word R Input MCS Serial Number High N/A 0 - 65535 N/A 30551 552
HW Part R Input MCS HW Part Number 10204 0 - 65535 N/A 30552 553
FW Rev R Input MCS Firmware Revision N/A 0 - 65535 N/A 30553 554
CT Secondary R Input Current Transformer Secondary Turns N/A 0 - 65535 N/A 30554 555
CT Primary R Input Current Transformer Primary Turns 1 0 - 65535 N/A 30555 556
RMS Current mA R Input Secondary RMS Current N/A 0 - 20000 mA 30556 557
RMS Current Primary R Input Primary RMS Current N/A 0 - 400 A 30557 558
Temperature R Input Unit Temperature N/A -40 - 80 °C °C / °F 30558 559
Modbus Current Sensor (MCS7) - 30560 to 30568
Serial Number Low Word R Input MCS Serial Number Low N/A 0 - 65535 N/A 30560 561
Serial Number High Word R Input MCS Serial Number High N/A 0 - 65535 N/A 30561 562
HW Part R Input MCS HW Part Number 10204 0 - 65535 N/A 30562 563
FW Rev R Input MCS Firmware Revision N/A 0 - 65535 N/A 30563 564
CT Secondary R Input Current Transformer Secondary Turns N/A 0 - 65535 N/A 30564 565
CT Primary R Input Current Transformer Primary Turns 1 0 - 65535 N/A 30565 566
RMS Current mA R Input Secondary RMS Current N/A 0 - 20000 mA 30566 567
RMS Current Primary R Input Primary RMS Current N/A 0 - 400 A 30567 568
Temperature R Input Unit Temperature N/A -40 - 80 °C °C / °F 30568 569
Modbus Current Sensor (MCS8) - 30570 to 30578
Serial Number Low Word R Input MCS Serial Number Low N/A 0 - 65535 N/A 30570 571
Serial Number High Word R Input MCS Serial Number High N/A 0 - 65535 N/A 30571 572
HW Part R Input MCS HW Part Number 10204 0 - 65535 N/A 30572 573
FW Rev R Input MCS Firmware Revision N/A 0 - 65535 N/A 30573 574
CT Secondary R Input Current Transformer Secondary Turns N/A 0 - 65535 N/A 30574 575
CT Primary R Input Current Transformer Primary Turns 1 0 - 65535 N/A 30575 576
RMS Current mA R Input Secondary RMS Current N/A 0 - 20000 mA 30576 577
RMS Current Primary R Input Primary RMS Current N/A 0 - 400 A 30577 578
Temperature R Input Unit Temperature N/A -40 - 80 °C °C / °F 30578 579
