DESCRIPTION OF PROGRAMMING PARAMETERS
Parameter /
Default Value
Name /
Description
Range
Function
Set on
RUN
4 DIGIT I MODE=1
G4.1.4 /
Selection of
Digital Inputs
configuration
0 – 5
It allows user to configure the digital inputs for different functions. All the options
described below will program to all the digital inputs simultaneously, except for
option ‘1  All Programmable’, which allows to configure their in a separate way.
OPT
DESCRIPTION
FUNCTION
0
3 WIRES
‘Start/Stop and Reset’ by terminals.
DI1 = 01 Start (NO)
DI2 = 04 Stop 1-Reset (NC)
DI3 = 03 Stop 2-Reset (NC)
DI4 = 15 Reference 2 (NO)
DI5 = 10 Speed Inversion (NO)
DI6 = 17 Control 2 (NO)
1
ALL
PROGRAMMABLE
Inputs configuration individually by
user. See G4.1.5 to G4.1.10.
2
MREF 2 WIRES
Digital inputs 5 and 6 are
programmed as multiple references
(of speed or PID references) for up
to 4 preset speeds. The remaining
inputs are user programmable.
PARM
DI5
DI6
G14.4
0
0
G14.5
0
X
G14.6
X
0
G14.7
X
X
Note: It is necessary to set G3.1
REF1 SPD=MREF or G3.2 REF2
SPD=MREF.
3
MREF 3 WIRES
Digital inputs 4, 5 and 6 are
programmed as multiple references
(of speed or PID references) for up
to 7 preset speeds. The remaining
inputs are user programmable.
PARM
DI4
DI5
DI6
G14.1
0
0
X
G14.2
0
X
0
G14.3
0
X
X
G14.4
X
0
0
G14.5
X
0
X
G14.6
X
X
0
G14.7
X
X
X
Note: It is necessary to set G3.1
REF1 SPD=MREF or G3.2 REF2
SPD=MREF.
Note: See following page.
