Power Electronics SD700 Series User Manual

POWER ELECTRONICS
SD700
DESCRIPTION OF PROGRAMMING PARAMETERS
57
Parameter /
Default Value
Name /
Description
Range
Function
Set on
RUN
3 BAUDS=9600
G20.1.3 /
Communication
speed
600
1200
2400
4800
9600
19200
Sets the data transmission speed for MODBUS serial communications. This rating
should be the same as the rating of the master of the communication bus on
which the drive is integrated.
YES
4 PARITY=NONE
G20.1.4 /
Communication
parity
ODD
NONE
EVEN
MODBUS parity setting. Used for data validation. If you do not want to validate
data, set this parameter to ‘NONE’. Parity selection should be the same as the
parity of the master of the communication bus on which the drive is integrated.
YES
DispBR= 4800
Display
communication
speed
1200
2400
4800
9600
Set the baud rate of the communication between the display and the control
power board.
YES
4.20.3. Subgroup 20.2 – S20.2: PROFIBUS (*)
Parameter /
Default Value
Name /
Description
Range
Function
Set on
RUN
1 NODE ADDR=10
NODE ADDRESS
G20.2.1 / Slave
address in
Profibus network
1 to 255
Sets the identification address assigned to the drive for communication via
Profibus network. If communication is required with several drives a different
address is required for each unit.
YES
(*) Note: Available if G20.0.1 = 1 Profibus
4.20.4. Subgroup 20.3 – S20.3: CANOPEN (*)
Parameter /
Default Value
Name /
Description
Range
Function
Set on
RUN
1 CO NODEID=0
G20.3.1 /
Canopen slave
address
0 to 127
The Node slave address is assigned
YES
2 CO BAUD=1Mbps
G20.3.2 / Bus
speed connected
to drive
125Kbps
250Kbps
500Kbps
1Mbps
Set the bus speed at which the drive will be connected.
YES
3 CO REF sp=+0.0%
G20.3.3 /
Canopen
Speed
Display screen through which the speed referenced can be seen through the
Canopen
YES
(*) Note: Available if G20.0.1 = 4 CanOpen
4.20.5. Subgroup 20.4 – S20.4: DEVICENET (*)
Parameter /
Default Value
Name /
Description
Range
Function
Set on
RUN
1 DN MAC ID=0
G20.4.1 /
Devicenet MAC
ID
0 to 63
DeviceNet MAC ID setting. Each device must be assigned a unique MAC ID
within the network.
MAC ID can be changed at any time, but it will come into effect after power-
cycling the drive. The default value is 0x00..
YES
2DNBaud=500Kbps
G20.4.2 /
Devicenet Baud
rate
125Kbps
250Kbps
500Kbps
Choose the DeviceNet Baud Rate (set by Master device)
OPTIONS
DESCRIPTION
0
125 Kbps
1
250 Kbps
2
500 Kbps
DeviceNet Baud Rate can be changed at any time, but it will come into effect after
power-cycling the drive.
YES
