DESCRIPTION OF PROGRAMMING PARAMETERS
27
Parameter /
Default Value
Name /
Description
Range
Function
Set on
RUN
10 DIGITL IN6=17
G4.1.10 / Multi-
function Digital
Input 6
configuration
00 – 75
Note: Coming from the previous page.
OPT
DESCRIPTION
FUNCTION
21
DC BRAKE
It activates or deactivates dynamic
brake unit. (NO)
22
START MODE 2
To select the alternative starting
mode (Ramp / Spin) (NO)
23
CURRENT LIMI2
To select the alternative current limit.
(NO)
24
EXTERN EMERGE
To generate the fault ‘F56
EMERGEN.STOP’. (NC). See Note.
25
FREMAQ FLT
It is an emergency stop which
indicates fault in the freemaq filter
(NC). Drive will trip by fault 78 TMP
FREEMAQ.
26
SPEED/TORQUE (*)
Switches between speed mode (NO)
and torque mode (NC)
27
STRT/STOP + INV
Start/Stop + rotation reversal. Start
the equipment with this digital input
means starting in the opposite
direction of the reference speed sign.
28
Dig Output FB
(NC) drive works normally, but, in
OPEN state, when the [G8.1.35]
expires, drive will trip by fault 55. See
parameter G8.1.34..
40
U.STOP
It stops the drive regardless of control
mode & program selection configured
(NO).
Parameters 70 and 75 available with the pump software.
NO
(*)Available if G19.1.1 = VECT and G19.1.2 = PMC/AVC
Note: The user can choose this option independently of the selected program (STÁNDARD or PUMP) or the control
mode used (LOCAL, REMOTE, and SERIAL COMMS).
4.4.2. Subgroup 4.2 – S4.2: Analogue Input 1
Parameter /
Default Value
Name /
Description
Range
Function
Set on
RUN
1 SENSOR 1 ?=N
G4.2.1 / To
enable sensor of
Analogue Input 1
N
Y
It allows user to configure analogue input 1 for use with a sensor and activates the
parameters which are necessary to set it up. See G4.2.2 up to G4.2.7.
OPTION
FUNCTION
N=NO
The analogue input will remain scaled in default
units (%).
Y=YES
The analogue input and any variables relating to
the analogue input will be configured in the
engineering units selected in G4.2.2.
YES
2 SENSOR 1=l/s
[3]
G4.2.2 /
Selection of
sensor 1 units
%
l/s
m³/s
l/m
m³/m
l/h
m³/h
m/s
m/m
m/h
Bar
kPa
Psi
m
ºC
ºF
ºK
Hz
rpm
It allows selection of different units of measurement for analogue input 1
according to the sensor that is used.
If this parameter is modified, the minimum and maximum values of the sensor
range must be adjusted to ensure correct configuration. Therefore, the following
set values should be checked:
'G4.2.5 Smi1=+0.0l/s'  Minimum range of sensor.
'G4.2.7 Sma1=+10.0l/s'  Maximum range of sensor.
YES
[3]
Available only when 'G4.2.1 SENSOR 1 = Y'.
