Power Electronics SD700 Series User Manual

SD700
POWER ELECTRONICS
66
MODBUS COMMUNICATION
5.4.2. Programming Parameters
Parameter
Screen
Description
Address
Range
Modbus Range
G1.1
1 LOCK PARMTRS=0
Parameter lock
-
0 to 2
-
G1.2
2 PASSWORD=OFF
Access password
-
OFF,
0000 to 9999
-
G1.3
3 PSW ERR=XXXX
Unlock password recovery
-
0000 to 9999
-
G1.4
4 LANGUA=ESPANOL
Language selection
-
ENGLISH
ESPANOL
DEUTSCH
PORTUGE
-
G1.5
5 INITIALISE=0
Parameter initialize
-
0 to 5
-
G1.6
6 SHORTmenu=NO
To hide some configuration menus
-
NO
YES
-
G1.7
7 PROG= STANDAR
Program activation
-
STANDARD
PUMP
-
G1.8
SV1.8 Visual
G1.11
11 FAN CTRL=FIXE
Drive fan control mode
40549
RUN
TEMP
FIX
0 to 2
G.1.10.1
1 UPLOAD=N
Save parameters from drive to display.
NO
YES
0 to 1
G1.10.2
2 DOWNLOAD=N
Save parameters from drive to display.
NO
YES
0-1
G1.12
12 RECT.BRIDGE=0
Amount of pulses of the rectifier bridge
40580
0 to 3
0 to 3
G1.14
14 SER GRP PWD =
OFF
Group reserved for the Technical Service
G2.1
1 MTR CUR=A
Motor rated current
40282
1 to 9999A
1638 to 12288
G2.2
2 MTR VOLT=400V
Motor rated voltage
40283
220 to 999V
220 to 999
G2.3
3 MTR PWR=Kw
Motor rated power
40285
0 to 6500kW
0 to 65000
G2.4
4 MTR RPM=1485
Motor rpm
40286
0 to 24000 rpm
0 to 24000
G2.5
5 MTR PFA=0.85
Cosine Phi
40288
0 to 0.99
0 to 99
G2.6
6 MTR FRQ=50Hz
Motor rated frequency
40284
0 to 100Hz
0 to 100
G2.7
7 MTR COOLN=63%
Motor cooling at zero speed
40287
OFF; 5 to 100%
8274;410 to 8192
G3.1
1 REF1 SPD=LOCAL
Reference source 1 of speed
40122
NONE
AI1
AI2
AI1+AI2
FIB_1
LOCAL
MREF
PMOT
PID
COMMS
FIB_2
0 to 11
G3.2
2 REF2 SPD=LOCAL
Reference source 2 of speed
40123
NONE
AI1
AI2
AI1+AI2
FIB_1
LOCAL
MREF
PMOT
PID
COMMS
FIB_2
0 to 11
G3.3
3 LOCAL SP=+100%
Local Speed Reference
40124
-250 to +250%
-20480 to + 20480
G3.4
4 REF1 TQ = LOCAL
Torque reference supply 1
40125
NONE
AI1
AI2
AI1+AI2
FIB_1
LOCAL
MREF
PID
COMMS
FIB_2
0 to 11
