POWER ELECTRONICS
SD700
DESCRIPTION OF PROGRAMMING PARAMETERS
43
4.9.2. Subgroup 9.2 – S9.2: Comparator 2
Parameter /
Default Value
Name /
Description
Range
Function
Set on
RUN
1 COMP 2 SEL=00
G9.2.1 / Source
selection for
Comparator 2
00 – 22
Selection of Comparator 2 source. Selection options are the same as Comparator
1. See parameter G9.1.1.
NO
2 COMP 2 TYPE=0
G9.2.2 /
Comparator 2
type selection
0 – 1
It allows selecting the operation mode of Comparator 2.
OPT.
DESCRIPTION
FUNCTION
0
Normal
Comparator will be activated when
the ON condition is given and will be
deactivated when the OFF condition
is given.
1
Window
Comparator will be activated when
signal is within the limits 1 and 2,
and additionally when limit 2 is
higher than limit 1. If limit 2 is lower
than limit 1, comparator output
logical function will be inverted.
YES
3 SP C2 ON=+100[%]
C2 ACTIVAT LEVEL
G9.2.3 /
Activation value
of Comparator 2
in Normal mode
-250% to
+250%
It selects the activation value of Comparator 2 output. The comparator output will
be activated if comparator source signal, selected in G9.2.1, is higher than the
value set here, and On delay time G9.2.6 has elapsed.
Note: This parameter is only displayed in Normal mode of the comparator 'G9.2.2
COMP 2 TYPE=0'.
YES
4 LIM 2 C2=+100[%]
C2 WINDOW LIMIT2
G9.2.4 / Limit 2
for Comparator 2
in Window mode
-250% to
+250%
It defines one of the limits to activate Comparator 2 in Window mode. The
comparator output will be activated if comparator source signal, selected in
G9.2.1, is within the two limits G9.2.4 and G9.2.5, and ON delay time G9.1.6 has
elapsed.
Note: This parameter is only displayed in Window mode of the comparator
'G9.2.2 COMP 2 TYPE=1'.
YES
5 LIM 1 C2=+0[%]
C2 WINDOW LIMIT1
G9.2.5 / Limit 1
for Comparator 2
in Window mode
-250% to
+250%
It defines one of the limits to activate Comparator 2 in Window mode. The
comparator output will be activated if comparator source signal, selected in
G9.2.1, is within the two limits G9.2.4 and G9.2.5, and ON delay time G9.2.6 has
elapsed.
Note: This parameter is only displayed in Window mode of the comparator
'G9.2.2 COMP 2 TYPE=1'.
YES
6 T C2 ON=0.0s
C2 ACTIVAT DELAY
G9.2.6 / ON
delay time for
Comparator 2
0.0 – 999s
Delay time for the Comparator 2 output activation. When the activation condition is
given in Normal or Window mode, the timer delays the activation of this signal for
the time set in this parameter.
YES
7 SP C2 OF=+0[%]
C2 DEACTIV LEVEL
G9.2.7 /
Deactivation
value of
Comparator 2 in
Normal mode
-250% to
+250%
This value selects the deactivation point of Comparator 2 output. The comparator
output will be deactivated if comparator source signal, selected in G9.2.1, is lower
than the value set here, and OFF delay time G9.2.8 has elapsed.
Note: This parameter is only displayed in Normal mode of the comparator 'G9.2.2
COMP 2 TYPE=0'.
YES
8 T C2 OF=0.0s
C2 DEACTIV DELAY
G9.2.8 / OFF
delay time for
Comparator 2
0.0 – 9999s
Delay time for the Comparator 2 output deactivation. When the deactivation
condition is given in Normal or Window mode, the timer delays the deactivation of
this signal for the time set in this parameter.
YES
9 SEL FUNT C2=00
G9.2.9 /
Selection of
output function
for Comparator 2
00 – 15
Several internal functions can be activated for Comparator 2 according to the
systems requirements. These functions are described in the table of parameter
G9.1.9.
NO
