FAULT MESSAGES. DESCRIPTIONS AND ACTIONS
81
6.2. Procedure for Fault Solutions
DISPLAY
POSSIBLE CAUSE
ACTIONS
F0 NO FAULT
F1 I LIM FLT
Motor output short circuit:
Check output cables and motor for possible wiring
faults or short circuits.
Wiring fault.
Circuit fault.
Motor fault.
F2 V LIM FLT
High voltage peak on the input.
Check conditions of input power supply. Decrease
deceleration ramps.
High load regeneration.
Deceleration ramp too high (parameters ‘G5.2
DECEL1’ and ‘G5.4 DECEL2’).
F3 PDINT FLT
See faults F1 and F2.
See faults F1 and F2.
F4 OVERLOAD U+
F5 OVERLOAD U-
F6 OVERLOAD V+
F7 OVERLOAD V-
F8 OVERLOAD W+
F9 OVERLOAD W-
Short circuit.
Check if there are possible wiring faults or a motor
fault. If the fault persists after disconnecting output
wires request technical assistance.
Extreme over current, equipment overload.
Wiring fault; circuit fault.
Desaturation of IGBT; IGBT fault.
F10 SAFE STOP
See possible causes for faults F4 – F9.
See actions for F4 – F9.
Safe stop contact of the drive has been activated.
Revise the external circuit, where the safe stop
contact is connected, that produces the activation
of this contact into the drive.
F11 VIN LOSS
Input power is incorrect, damaged fuses.
Check conditions of input power supply.
Input wiring is incorrect.
Check wiring.
F12 IMB V IN
Input power is incorrect, damaged fuses.
Check conditions of input power supply.
Input wiring is incorrect.
Check wiring.
F13 HI V IN
Input power is incorrect.
Check input power conditions.
Incorrect setting of parameter ‘G11.6 HIGH VOLT’.
Check parameters settings.
F14 LW V IN
Input power is incorrect, damaged fuses.
Check input power conditions.
Incorrect setting of parameter ‘G11.4 LOW VOLT’.
Check parameters settings.
F15 CURL Vdc
Input power is incorrect.
Check input power conditions, load type of the
application, and all of the motor mechanical parts.
If the fault persists after disconnecting output wires,
request technical assistance.
Motor is driving an unstable load.
One of the input fuses is damaged.
F16 HI Vdc
High voltage peak on the input.
Check conditions of input power supply.
High load regeneration.
Check stop conditions of the drive.
Deceleration ramp too high (parameters ‘G5.2
DECEL1’ and ‘G5.4 DECEL2’).
Decrease deceleration ramps.
F17 LW Vdc
Input power is wrong, damaged fuses.
Check conditions of input power supply.
F18 IMB V OUT
Motor is driving an unstable load.
Check motor circuit completely in case of possible
wiring faults or motor fault. If the fault persists after
disconnecting output wires, request technical
assistance.
Motor wiring fault.
Motor is wrong.
F19 IMB I OUT
Motor is supporting unstable loads.
Check motor circuit completely in case of possible
wiring faults or motor fault.
Motor wiring fault.
Motor is wrong.
F20 GROUND FLT
Motor or wiring has short-circuited to ground.
Disconnect the motor and wiring of the SD700 and
check motor insulation.
Ground is incorrectly connected or wrong.
Check and improve the ground connection system.
F21 I LIM T/O
Motor stalled. Heavy load.
Motor mechanical brake is coupled.
Check the motor load.
Increase maximum current limit.
F22 TQ LIM T/O
Motor stalled. Heavy load.
Motor mechanical brake is coupled.
Check the motor load.
Increase maximum torque limit.
F23 Min Spd Lm
Speed reference is lower or equal than the speed
limit.
Check the reference source and the motor load.
Motor speed is out of control or motor is not
accelerating due to the load.
Verify speed limits.
