Power Electronics SD700 Series User Manual

POWER ELECTRONICS
SD700
MODBUS COMMUNICATION
65
5.4. Summary of Modbus Addresses
5.4.1. Modbus Register ‘COMMS STATUS’
This register supplies information about the communication status of the drive, as the following
table shows:
Modbus
Address
Bit
Description
Meaning on ‘0’
Meaning on ‘1’
40558
0
RUN
Drive stopped
Drive running
1
FAULT
No Fault
Fault
2
WARNING
No Warning
At least one warning present
3
READY
The drive is not ready to start
(any fault or warning is
present)
The drive is ready to start (no
fault and no warning)
4
EXTERNAL POWER SUPPLY
The drive is powered through
internal power supply
The drive is powered through
external power supply
5
DELAYING START
Not delaying start
Delaying start
6
MOTOR OVERLOAD
Motor overload warning
(MOL) is not active
Motor overload warning
(MOL) is active
7
MOTOR OVERLOAD FAULT
Motor overload fault (F25) is
not present
Motor overload fault (F25) is
present
8
RESERVED
Reserved
Reserved
9
DRIVE AT SET SPEED
Motor speed is different to the
reference speed
Motor speed has reached the
value set as reference
10
CURRENT LIMIT
Current limitation warning
(ILT) is not present
Current limitation warning
(ILT) is present
11
VOLTAGE LIMIT
Voltage limitation warning
(VLT) is not present
Voltage limitation warning
(VLT) is present
12
TORQUE LIMIT
Torque limitation warning
(TLT) is not present
Torque limitation warning
(TLT) is present
13
COMPARATOR 1
Comparator 1 is ‘OFF’
Comparator 1 is ‘ON’
14
COMPARATOR 2
Comparator 2 is ‘OFF’
Comparator 2 is ‘ON’
15
COMPARATOR 3
Comparator 3 is ‘OFF’
Comparator 3 is ‘ON’
