SD700

POWER ELECTRONICS

COMMONLY USED CONFIGURATIONS

7. COMMONLY USED CONFIGURATIONS

7.1. Start / Stop Commands and Speed Reference by Keypad

7.1.1. Parameters Configuration

Parameter

Name / Description

Value

G1: Options Menu.

4 LANG=ENGLISH

G1.4 / Language selection

ENGLISH

7 PROG = STANDARD

G1.7 / Program activation

STANDARD

G2: Motor Nameplate.

1 MTR CURR=00.00A

G2.1 / Motor rated current

__A (Set according to motor nameplate).

2 MTR VOLT=400V

G2.2 / Motor rated voltage

__V (Set according to motor nameplate).

3 MTR PWR=00.0kW

G2.3 / Motor rated power

__kW (Set according to motor nameplate).

4 MTR RPM=1450

G2.4 / Motor rpm

__rpm (Set according to motor nameplate).

5 MTR PFA=0.84

G2.5 / Cosine Phi

__ (Set according to motor nameplate).

6 MTR FRQ=50Hz

G2.6 / Motor frequency

__Hz (Set according to motor nameplate).

7 MTR COOL=63%

G2.7 / Motor cooling at zero speed

Use the following values as a reference:

Submersible pumps and non-deflagrating motors  5%

Self-cool motor  63%

Force-cooled motor  100%

G3: References.

1 REF1 SPD=LOCAL

G3.1 / Speed reference source 1

LOCAL  Reference will be determined by keypad and is set in

G3.3 'Local Speed Reference'.

3 LOCAL SPD=+100%

G3.3 / Local Speed Reference

100%

G4: Inputs – S4.1: Digital Inputs.

1 CNTROL MODE1=1

G4.1.1 / Main Control Mode

1  LOCAL (Drive control is done by keypad).

3 RESET MODE=Y

G4.1.3 / Reset by keypad

Y  YES (Enables reset by keypad).

7.2. Start / Stop Commands by Terminals and Speed

Reference by Analogue Input

7.2.1. Parameters Configuration
