FAULT MESSAGES. DESCRIPTIONS AND ACTIONS
83
DISPLAY
POSSIBLE CAUSE
ACTIONS
F49 SPD LIMIT
MAX
Speed reference is higher or equal than the speed
limit.
Check the reference source and the motor load.
Motor speed is out of control or motor is
accelerating because of the load.
Verify speed limits.
F50 PSU FAULT
Damaged power supply.
Reset the equipment and if the fault persists
request technical assistance.
F51 SCR TEMP
Temperature limits for SD700 rectifier have been
exceeded.
Verify that the ambient conditions are proper for
the equipment.
Be sure that there is nothing obstructing the
cooling fans (dust, papers, dirt, etc) and that these
rotate correctly.
F52 FAN P.SUPP
Fans of the equipment are operating wrong.
Verify that fans are not obstructed.
Check that fans are not dirty and rotate correctly.
Power supply of the fans has been overheated.
Wait for the temperature of the power supply
decreases down to a value in normal conditions
and restart it. You can disconnect the equipment,
connect it again, and restart the power supply
again. If the fault persists request technical
assistance of Power Electronics.
F53 INTRNL TEMP
The limit of internal temperature of the electronics
chamber has been exceeded.
Verify that the ambient conditions are proper for
the equipment.
Be sure that there is nothing obstructing the
cooling fans (dust, papers, dirt in general) and that
these rotate correctly.
F54 WATCHDOG
A fault in the microcontroller has occurred.
Disconnect and re-connect the input power of the
drive. If the fault persists request technical
assistance of Power Electronics.
F55 DO Feedbck
Timeout of the parameter G8.1.35 has been
exceeded.
Check the feedback of the digital output configured
in the parameter G8.1.34.
F56 EMERG.STOP
An external trip has been produced by closing a
contact on the digital input configured in this
option.
Verify the wiring of digital input.
Check the installation.
F57 PUMP OvLd
High current used by the motor due to heavy load.
Check the motor load.
Check if the motor cooling is appropriate.
Check the setting of the parameters related to
pump overload in group G11.
The load exceeds the capacity of the motor cooling
under normal operating conditions.
Incorrect setting of the parameters related to pump
overload.
Phase loss of the motor or a fault in motor
windings.
F58 PROFI.TOUT
The communication between Profibus Master and
Slave is cut off.
Revise the Profibus wiring and the configuration in
the Master (PLC).
F60 EIP/DN T.O
The active connection with the Ethernet/IP Client
has been lost.
Check the Ethernet/IP connection of the client
(PLC, PC).
F61 NO INPUT V
The start command has been given while the drive
is powered through the External 24V Power
Supply.
Restore 3-Phase power supply to the drive before
giving the start command.
F73 FLT COMP 1
The comparator 1 has been disabled.
Check the configuration of the comparator 1.
F74 FLT COMP 2
The comparator 2 has been disabled.
Check the configuration of the comparator 2.
F75 FLT COMP 3
The comparator 3 has been disabled.
Check the configuration of the comparator 3.
F76 SLAVE O.F
Failure of a slave.
Check the slave status.
F77OPT FIB TO
The fiber is broken.
Check wiring.
Check the equipment status.
One of the equipments of the network is turned off.
Improper connection.
F78 TMP
FREEMAQ
The temperature of the filter is very high.
Check the ventilation.
Check the thermal contacts.
Check the power contactor
Check the wiring to the digital input configured as
“FREMAQ FLT”.
