Power Electronics SD700 Series User Manual

POWER ELECTRONICS
SD700
DESCRIPTION OF PROGRAMMING PARAMETERS
61
4.21.3. Subgroup 21.3 – S21.3: ETHER./IP
Parameter /
Default Value
Name /
Description
Range
Function
Set on
RUN
1 CONTROL MODE=0
G21.3.1 / Control
mode of the drive
0 – 2
This parameter allows setting how the drive will be controlled.
OPT.
DESCRIPTION
FUNCTION
0
LOCAL
The drive can be started and stopped
like the equipment is not connected to
the Ethernet network, this means,
from the settings in G4.1.1 or G4.1.2.
1
NETWORK
The drive can only be controlled
through the Ethernet/IP Client by
means of the Ethernet board. In this
case, the setting of G4.1.1 and G4.1.2
is ignored.
2
NET DECIDES
In this case, the Ethernet/IP Client,
through the Ethernet board, will inform
the drive all the time about who is
controlling it.
NO
2 REFEREN.MODE=0
G21.3.2 /
Reference mode
of the drive
0 – 2
This parameter allows setting from where the speed reference is provided to the
drive.
OPT.
DESCRIPTION
FUNCTION
0
LOCAL
The drive will take the reference from
parameters G3.1 or G3.2.
1
NETWORK
The reference will only be taken
through the Ethernet/IP Client by
means of the Ethernet board. In this
case, the setting of G3.1 and G3.2 is
ignored.
2
NET DECIDES
In this case, the Ethernet/IP Client,
through the Ethernet board, will inform
the drive all the time about who is
providing the speed reference to it.
NO
3 FAULT MODE = 2
G21.3.3 / Fault
Mode
0 – 2
It is used to select what has to do the drive in case of communication fault:
OPT
FUNCTION
FAULT
Drive trips by fault F60.
IGNORE
The drive keeps operating despite communication loss.
PE BEHV
While the communication wire is not well connected,
the drive still tripping.
YES
