Power Electronics SD700 Series User Manual

POWER ELECTRONICS
SD700
DESCRIPTION OF PROGRAMMING PARAMETERS
23
4.4. Group 4 – G4: Inputs
4.4.1. Subgroup 4.1 – S4.1: Digital Inputs
Parameter /
Default Value
Name /
Description
Range
Function
Set on
RUN
1 CNTROL MODE1=1
G4.1.1 / Main
Control Mode
0 – 4
It allows user to set the control mode for the drive commands (Start/Stop, Reset,
...).
OPT
DESCRIPTION
FUNCTION
0
NONE
Control mode 1 is not operative.
1
LOCAL
Drive control is done by keypad.
2
REMOTE
Drive controlled through control
terminals.
3
COMMS
Drive controlled through
communication bus.
4
FIBER
Drive controlled through optical
fiber
If the parameter G20.0.1 is set as OFC, the following options are shown too
OPT
DESCRIPTION
FUNCTION
4
FIBER
Drive controlled through optical
fiber
NO
2 CNTROL MODE2=2
G4.1.2 /
Alternative
Control Mode
0 – 4
It allows user to set the secondary control mode for the drive commands
(Start/Stop, Reset, ...).
OPT
DESCRIPTION
FUNCTION
0
NONE
Control mode 2 is not operative.
1
LOCAL
Drive control is done by keypad.
2
REMOTE
Drive controlled through control
terminals.
3
SERIAL COMMS
Drive controlled through
communication bus.
4
FIBER
Drive controlled through optical
fiber
If the parameter G20.0.1 is set as OFC, the following options are shown too
OPT
DESCRIPTION
FUNCTION
4
FIBER
Drive controlled through optical
fiber
Note: Control mode 2 will be activated through digital inputs exclusively. To use
this set one of the digital inputs to ‘17  CONTROL 2’. When this input is
activated, auxiliary control mode will be activated.
NO
3 RESET MODE=Y
G4.1.3 / Reset
from keypad
N
Y
It allows user to reset faults from the keypad unit (LOCAL).
OPTION
FUNCTION
N=NO
It is not possible to reset from the keypad unit.
Y=YES
The drive can be reset via the reset button on the
keypad unit.
YES
