DESCRIPTION OF PROGRAMMING PARAMETERS
49
Parameter /
Default Value
Name /
Description
Range
Function
Set on
RUN
5 F1 AUTO RST=0
G12.5 / Selection
of fault 1 to be
reset
0 – 27
If Auto Reset selection is enabled, the SD700 will automatically resets the faults
selected according to the following table:
OPT.
DESCRIPTION
FUNCTION
0
0 NO AUTO
RESET
If G12.5 to G12.8 is set with this
value, Auto Reset will not be
undertaken.
1
ALL THE FLTS
All faults will be reset automatically.
2
11 VIN LOSS
To reset fault F11, input power loss.
3
13 HIGH V IN
To reset fault F13, high input
voltage.
4
14 LOW V IN
To reset fault F14, low input voltage.
5
18 DSQ V
OUT
To reset fault F18, output voltage
imbalance.
6
19 DSQ I OUT
To reset fault F19, output current
imbalance.
7
20 IGND
FAULT
To reset fault F20, ground fault.
8
21 ILT
TIMEOUT
To reset fault F21, current limit time
out.
9
22 TLT
TIMEOUT
To reset fault F22, torque limit time
out.
10
27
SOFTCHRGE
To reset fault F27, DC Bus charge
fault.
11
40 FLT
To reset fault F40, motor PTC fault.
12
41 COMMS
TRIP
To reset fault F41, fault signal from
communication net.
13
42 AIN1
MISSING
To reset fault F42, Analogue Input 1
loss.
14
43 AIN2
MISSING
To reset fault F43, Analogue Input 2
loss.
15
47 COMMS
ERROR
To reset fault F47, communication
time out.
16
49 SPEED
LIMT ER
To reset fault F49, exceeded speed
limit.
17
65 LOW
PRESSURE
To reset fault F65, low pressure.
18
66 HI
PRESSURE
To reset fault F66, maximum
pressure.
19
67 LOW
WATER
Fault F67 is reset, low water.
20
31 SCR L1
FAULT
To reset fault F31, fault on phase L1
of rectifier.
21
32 SCR L2
FAULT
To reset fault F32, fault on phase L2
of rectifier.
22
33 SCR L3
FAULT
To reset fault F33, fault on phase L3
of rectifier.
23
68
CAVIT/UNDERL
To reset fault F68, cavitation /
underload trip.
27
56 EXTER
FAULT
Resets F50 fault, Emergency Stop.
Caution: When the fault selection for auto reset is undertaken the user
should pay special attention to option 1 ‘All the faults’. In this case, the protections
of the drive and motor will be disabled. It is not recommended to select this option
since the drive could try to reset internal trips causing serious damage to the
drive.
YES
6 F2 AUTO RST=0
G12.6 / Selection
of fault 2 to be
reset
0 – 27
YES
7 F3 AUTO RST=0
G12.7 / Selection
of fault 3 to be
reset
0 – 27
YES
8 F4 AUTO RST=0
G12.8 / Selection
of fault 4 to be
reset
0 – 27
YES
