powersoft X8 User Manual

INDEX
42
X8 | SERVICE MANUAL
Access the Speaker preset manager window by tapping one of the
Speaker button.
The Output Channel window grants access to the Output’s
Monitoring Functions, as well as Output Gain/Mute control and
Active Damping Factor Activation, unless the preset has been
locked via Armonía.
Access the Meters’ section of the Output Channel Window by
tapping on the Meters’ button.
Further Metering functions are available within this window.
Access the Output Channel window by tapping one of the Output
Channel Buttons.
Access the Snapshot window by tapping one of the Snapshot
Button on the main page.
Select from one of the up to 200 speaker presets stored within the
amplier.
Or access the presets stored in an external USB drive by tapping
on the USB button.
It is also possible to delete the selected preset, or to clear the
whole preset list by tapping on the appropriate Trash Bin buttons.
Fine tune the selected lter.
SPEAKERS
OUTPUT CHANNEL
SNAPSHOTS

powersoft X8 Specifications

General

Channels	8
Signal to Noise Ratio	> 112 dB
Damping Factor	> 5000
Power Supply	Universal switching power supply (100-240V, 50/60Hz)
Networking	Ethernet
DSP	Yes, with FIR filters
Load Impedance	4Ω, 8Ω
Input Impedance	20 kΩ balanced
Cooling System	Variable speed fan
Frequency Response	5 Hz - 30 kHz
