X8 | SERVICE MANUAL
Within the Snapshot window it is possible to recall up to 50 user
dened Snapshots from the internal X Series Library, or from an
external USB drive.
Delete the Snapshot by tapping the Trash Bin Button.
In order to clear the Gang Settings on a given row, tap the Clear
button. Note that clearing does not inuence the settings.
Note that Ganging is device susceptible: Ganging data will be lost
once the Front Panel has been disconnected.
In case multiple devices are connected to the same Amplier
Platform (i.e. Armonía running on a computer while using the Front
Panel on another device), the Front Panel will display an error
message, and the Ganging conguration will be restored to its
default settings.
Access the Gang window by tapping one of the Gang Button.
Through this intuitive interface, it is possible to link the Advanced
EQ, Gain, Delay, Polarity, and Mute parameters within the channels.
GANG

powersoft X8 Specifications

General

Channels	8
Signal to Noise Ratio	> 112 dB
Damping Factor	> 5000
Power Supply	Universal switching power supply (100-240V, 50/60Hz)
Networking	Ethernet
DSP	Yes, with FIR filters
Load Impedance	4Ω, 8Ω
Input Impedance	20 kΩ balanced
Cooling System	Variable speed fan
Frequency Response	5 Hz - 30 kHz
