A --- 5 4
Powerware 9330 (10 kVA--40 kVA) Installation and Operation
164201300 Rev . N 013004
DESCRIPTION:
DATE:
DRAWING NO: SHEET:
REVI SION:
N
5of5
013004
LOCATION OF UPS CABINET TERMINALS
164201300---8
UPS CABINET CUSTOMER INTERFACE TERMINALS
X-SLOT
COMMUNICATIONS
BAY
X4 X3 X2 X1
COMMUNICATIONS
SERVER BOARD (CSB)
EXTERNAL BATTERY CABINET
POWER CO NNECTO R
TOP VIEW
POWERWARE 9330 (10 kVA-- 20 kVA)
CUSTOMER INTERFACE
CONDUIT LANDING PLATE
(REMOVE PANEL TO DRILL
OR PUNCH CONDUIT
HOLES.)
