The RIM can provide these signats:
UPS AVAIlABLE (connector pins 1 and 12)
Relay 1 is energized and the UPS is operating in Normal mode.
UPS OFF UNE (connector pins 3 and 13)
Relay 1 is not energized. indicating that the UPS is not operating in Normal mode. This
signal is the opposite of UPS Available.
UTfLfTY FAILURE (connector pins 6 and 15)
Relay 2 is energized. The UPS is on battery and the utility power to the UPS is not
available.
BATTERY WEAK (connector pins 5 and 14)
Relay 3 is energized, indicating that shutdown is imminent. The UPS has approximately 2
minutes of battery time remaining until it will no longer support the critical load.
Serial Communications Ports
Two serial communications potis are provided on the UPS. You can connect these ports
to a remote terminal and/or printer to view information similar to that shown on the LCD
screen of the UPS Monitor Panel.
For detailed information about serial communications
capabilities of this UPS, sea Powwnww
Plus SOS& Communications Guide.
