Mating Plug for Sub-D (6000/03)
_____________________________________________________________________________________________________________________________________
10-2
10.2 Mating Plug for Sub-D (6000/03)
A 50-wire subminiature type D connector can be used for each set of 10 channels (4-
pole). This connector has solder connections for each wire and a cable outlet for
round cables up to 12 mm diameter.
Two plugs are nessecary for connecting all 80 channels.
10.3 Pt100 Temperature Probes (3011 and 3012)
Pt100-Temperature Probe in 4-wire connection with handle.
Connection to the DMM via a 1.5m cable with 4 gold plated banana plugs.
Model Surface Probe 3011 Immersion Probe 3012
Sensor
Pt100
(Platinum RTD100)
Pt100
(Platinum RTD100)
Connection
4-wire 4-wire
Temp. Range (Sensor)
-50°C to 220°C -50°C to 600°C
max. Temp. (Handle)
-25°C to about 80°C -25°C to about 80°C
Accuracy (Sensor)
1/3 DIN B 1/3 DIN B
Probe Length
160mm without handle 160mm without handle
Diameter
Contact Surface:ø 9mm Pipe: ø 5mm
Cable Length
1,5m 1,5m
Connectors
4 Banana Plugs, 4mm 4 Banana Plugs, 4mm
10.4 Test Lead Set (3014)
The Test Lead Set consists of two, 1m long cables with shrouded, 4mm banana plugs
and two probe tips. The contacts of the plugs have low thermal voltages, which is
necessary for precise measurements.
