Prema DMM 5017 - Navigating in the Menu Structure

Navigating in the Menu Structure
_____________________________________________________________________________________________________________________________________
4-10
The structure of the menu is described in the following table:
1 MATHEMATICS 2 CONFIGURE 3 DEVICE
1*Offset
Ofs=x-a
a=+0.0000000E+0
2 ax+b
Lin = ax + b
a=+0.0000000E+0
b=+0.0000000E+0
3 Ratio
Rto = x / a
a=+0.0000000E+0
4 %Deviation
Dev=100(x-a)/a
a=+0.0000000E+0
5 dB ..
6 dBm
1 Start Mode
2 Filter
1*Auto Filter
2 Fast Auto Filt
3 Avrg Filt
3 Settings
1 Save Settings
2 Load Fact. Set
4 Calibration
1 Enter Value
2 Store Cal.
3 Load Cal.
4 Load Fact. Cal
1 Contrast N
2 Interface 1 IEEE-488
1 Address
2 * RS233
1 Xon/Xoff
2 RTS / CTS
3* no Handshake
3. Command Set
1. 5017
2. 6048 / 6047
3. 6001 / 5001 / 4001
3 Temp Sensor 1 Pt10 2 Pt25 3* Pt100
4 Pt500 5 Pt1000
4* Beeper
5 Display 1*Settings
2 Math
3 Channel
4 Sec Counter
6 Scanner 1* 4-pole, 20 CH
2 2-pole, 40 CH
3 1-pole, 80 CH
Table: Menu structure
The ‘*’ sign means that this menu item is activated.
