Prema DMM 5017 - Preselecting the Interface

The Menu "Device"
_____________________________________________________________________________________________________________________________________
4-18
Preselecting the Interface
The 5017 is equipped with a RS232 serial data interface and the IEEE-488 interface.
The interface which is to be activated can be set in this menu.
Keypress Display / Action
1.
MENU
-
IN KEY
'HYLFH
If this display does not appear, press the
Ø
-
KEY
until
it does appear.
2.
MENU
-
IN KEY
,QWHUIDFH
If this display does not appear, press the
×Ø
-
KEYS
until
it does appear.
3.
MENU
-
IN KEY
,(((
The IEEE488 interface is selected with the
MENU
-
IN KEY
.
4.
MENU
-
IN
-
KEY
$GGUHVV
Enter the device address and then to terminate the entry press the
MENU
-
IN KEY
.
5.
MENU
-
OUT KEY
Takes over the entry and steps up one menu level higher. Press
repeatedly to reach the measurement reading display.
Table: Setting the IEEE-488 interface
Keypress Display / Action
1.
MENU
-
IN KEY
'HYLFH
If this display does not appear, press the
Ø
-
KEY
until
it does appear.
2.
MENU
-
IN KEY
,QWHUIDFH
If this display does not appear, press the
×Ø
-
KEYS
until
it does appear.
3.
MENU
-
IN KEY
56
The RS232 interface is selected with the
MENU
-
IN KEY
.
4.
MENU
-
IN KEY
;RQ;RII
Select the handshake mode and then press the
MENU
-
IN KEY
to
confirm.
5.
MENU
-
OUT KEY
Takes over the entry and steps up one menu level higher. Press
repeatedly to reach the measurement reading display.
