Prema DMM 5017 - Display with Mathematics; Display with Channel

Display
_____________________________________________________________________________________________________________________________________
3-10
Display with Mathematics
Figure: Display with Mathematics
Selection with "Menu Device, Display, Math".
Abbreviation Meaning
OFS Offset x - a
LIN Linearization ax + b
RTO Ratio x / a
DEV % Deviation 100 * (x - a) / a
dB dB
dBm dBm
Table: Meaning of the Mathematics Abbreviations
Display with Channel
Figure: Display with Channels
Selection with Menu "Device, Display, Channel".
REAR
MATH FILT REM
9 2)6
AUTO
TRIG STORE ADR
REAR
MATH FILT REM
9 &
AUTO
TRIG STORE ADR
