Prema DMM 5017 - The Menu Configure; Start Mode; Trigger Mode; Filter

4 Manual Operation
_____________________________________________________________________________________________________________________________________
4-13
4.10 The Menu "Configure"
Start Mode / Trigger Mode
This menu activates start mode. Triggering can be performed manually or via the
external trigger socket.
Keypress Display / Action
1.
MENU
-
IN KEY
&21),*85(
If this display does not appear, press the
×
-
KEY
until it appears.
2.
MENU
-
IN KEY
6WDUW0RGH
3.
MENU
-
IN KEY
6WDUW0RGH
activates / deactivates start mode.
4.
MENU
-
OUT KEY
Takes over the entry and steps up one menu level higher; press
repeatedly to reach the measurement display
5. TRIG: 2
X
2
ND
-K
EY
Measurement of a value is started manually
Table: Selecting start mode
Filter
To increase disturbance suppression for better stability of the measurement readings,
the input signals can be passed through a digital filter which operates as moving
average filter for the last ten readings. After the first ten readings have come into the
filter loop, each new reading thereafter replaces the oldest one.
Two filters are available:
• Automatic average value filter (Auto Filter)
• Fast Automatic average value filter (Fast Auto Filter)
• Moving average filter (Avg. Filter)
