Difference between 5017 and 6001 concerning hardware
Function DMM 5017 / 5017SC DMM 6001 / 6001SC, 4001/4001SC
Display 7½ digit for Vdc and Ohms
LCD
6½ digit
LED matrix
Full scale 30 100 000 for Vdc and Ohms 1 999 999
Additional frequency / period / continuity -
AC
Measurements
AC and AC+DC
frequency range 3 Hz up to 1MHz
only AC + DC
frequency range 20 Hz up to 100 kHz
Overload Limit V/Lo-plug against ground: 250V
5017SC V/Hi to Lo: 1000V
V/Lo-plug against ground: 125V
6001-01 V/Hi to Lo: 125V
NMRR >100dB (PLL inside) 60dB
Integration Times from 20ms to 100s (6½ dgt from 0.2 s) from 50 ms to 10s (6½ dgt. from 1s)
Current Ranges Five: from 200µA to 2A Two ranges: 2mA / 2 A
Resistance
up to 30M
Ω
2- and 4-wire 2-wire max. 16 M
Ω
, 4 wire 100k
Ω
Temperature Pt10/Pt25/PT100/Pt500/Pt1000 Pt100
Memory - 100 values volatile
Trigger with trigger line (9-pole sub D connector)
or keystroke
with trigger line (3.5 mm jack plug)
Interface IEEE488, RS232 IEEE488
Filter switchable on/off or automatic -
Analog display - 100 dots
Math programs Offset, ax+b, Ratio, % Deviation Offset, %Dev, Incr, Ratio, dB, dBm
Front plugs
HI HI
Amps
V
Ω
Ω4
Sense
LO
HI
Guard
V
Ω
Α
Source
LO
Rear plugs Yes No
Switch Front/Rear manually, with open the instrument Relay
(with IEEE command or key board)
Optional
Scanner
20x4-pole, 40x2-pole, 80x1-pole
on two 50-pole sub D connector
different pin assignment
No current measurement
10x4-pole
on one 50-pole sub D connector
different pin assignment
current measurement possible
* ) DMM 5001/ 5001SC is compatible to the DMM 6001/6001 excluding Temperature and 4-wire Ohms measurement
