MBOX® USER MANUAL
Fixture Sub-Fixture Parameter Description
Output Master
continued...
(1 required, up to
32 total)
Keystone
Curve Enables and elects keystone curve/mode
Gamma Gamma of edge blend area
Edge Top Position/depth of top edge blend area
Edge Right Position/depth of right edge blend area
Edge Bottom Position/depth of bottom edge blend area
Edge Left Position/depth of left edge blend area
Keystone 1x Left/right position of top-left corner
Keystone 1y Down/up position of top-left corner
Keystone 2x Left/right position of top-right corner
Keystone 2y Down/up position of top-right corner
Keystone 3x Left/right position of bottom-right corner
Keystone 3y Down/up position of bottom-right corner
Keystone 4x Left/right position of bottom-left corner
Keystone 4y Down/up position of bottom-left corner
Linearity X Adjusts center of keystone surface left/right
Linearity Y Adjusts center of keystone surface down/up
Shutter
Shape Enables and selects shutter shape
Red Red Additive
Green Green Additive
Blue Blue Additive
Edge Softness Set the soft edge amount for all shutters
Shutter 1a Left-bottom | Left Amount
Shutter 1b Left-top | Left Angle
Shutter 2a Top-left | Top Amount
Shutter 2b Top-right | Top Angle
Shutter 3a Right-top | Right Amount
Shutter 3b Right-bottom | Right Angle
Shutter 4a Bottom-right | Bottom Amount
Shutter 4b Bottom-left | Bottom Angle
X Position Overall left/right position of shutters
Y Position Overall down/up position of shutters
Scale Overall scale of shutters
Rotation Overall rotation of shutters
Damping
Adds smoothing to shutter motion in 0.33sec
increments
Parameter Descriptions: Mbox Designer continued...
