PRG Mbox - Page 208

198
MBOX® USER MANUAL
Fixture Sub-Fixture Parameter Description
Layer Base
Opacity Transparency of the layer
Red Red subtractive & additive for layer
Green Green subtractive & additive for layer
Blue Blue subtractive & additive for layer
Brightness Brightness of layer
Contrast Contrast of layer
Texture Folder Selects numbered 2D content folder
Texture File Selects numbered le within Texture Folder
Play Mode Selects play mode of movie content
Play Speed Selects play speed of movie content
In Frame Sets in-frame of movie content
Out Frame Sets out-frame of movie content
Sync Stream
Selects 1 of 16 channels for playback syn-
chronization
Sync Offset Adjusts playback sync offset
Frame Blending
Adjusts the amount of interframe blending for
movie content
Texture Xfade
Type
Selects the type of crossfade for 2D content
on the layer
Texture Xfade
Time
Adjusts the duration of crossfades for 2D con-
tent on the layer
Object File Selects numbered le within Object Folder
X Position Moves the layer left/right
Y Position Moves the layer down/up
Scale Adjusts the size of 2D/3D content on the layer
X Scale
Adjusts the width of 2D/3D content on the
layer
Y Scale
Adjust the height of 2D/3D content on the
layer
Z Rotation
Adjusts rotation of the content around the Z
axis
X Rotation
Adjusts rotation of the content around the X
axis
Y Rotation
Adjusts rotation of the content around the Y
axis
Mix Select Assigns content on layer to a mix
Mix Mode Sets the mode for the selected mix
Blend Mode Selects a 2D blending mode
Draw Mode Selects a 2D draw mode (stenciling)
Image Remap
Selects image remapping conguration for the
layer
Parameter Descriptions: Mbox Studio continued...
