197
MBOX® USER MANUAL
Fixture Sub-Fixture Parameter Description
Output Master
continued...
(1 required, up to
8 total)
Shutter
Shape Enables and selects shutter shape
Red Red Additive
Green Green Additive
Blue Blue Additive
Edge Softness Set the soft edge amount for all shutters
Shutter 1a Left-bottom | Left Amount
Shutter 1b Left-top | Left Angle
Shutter 2a Top-left | Top Amount
Shutter 2b Top-right | Top Angle
Shutter 3a Right-top | Right Amount
Shutter 3b Right-bottom | Right Angle
Shutter 4a Bottom-right | Bottom Amount
Shutter 4b Bottom-left | Bottom Angle
Parameter Descriptions: Mbox Studio continued...
