MBOX® USER MANUAL
Value Effect Description Mod 1 Mod 2 Mod 3 Mod 4 Mod 5
93-95 Reserved
96 Distortion - Bump bump distortion radius scale x position y position
97
Distortion - Linear
Bump
linear bump distortion radius angle scale x position y position
98 Distortion - Hole hole distortion radius x position y position
99 Distortion - Pinch pinch distortion radius scale x position y position
100 Distortion - Torus torus distortion width radius x position y position
101 Distortion - Twirl twirl distortion radius angle x position y position
102 Distortion - Vortex vortex distortion radius angle x position y position
103
Distortion -
Lozenge
lozenge distortion radius refraction point 1 point 2
104
Distortion -
Circular Wrap
wraps image into tube
shape
radius angle x position y position
105
Distortion -
Circular Splash
clamps image from
center outwards
size x position y position
106 Distortion - Glass
applies a glass-like
texture
layer scale x position y position
107
Distortion -
Displacement
applies grayscale of
input image to layer to
create texture
layer scale
108-
112
Reserved
113 Smear - Horizontal
spread single column
over horizontal space
mixer column
114 Smear - Vertical
spread single row over
vertical space
mixer row
115-
117
Reserved
118 Pixellate - Square pixellates image, square radius angle scale x position y position
119
Pixellate -
Hexagonal
hole distortion radius x position y position
120 Crystallize
break up image into
crystal pattern
radius x position y position
121 Pointillize break image into points radius x position y position
122-
126
Reserved
127 Tile - 1 image tiling no gaps mixer divisions
128 Tile - 2 image tiling with gaps mixer
horizontal
divisions
horizontal
spacing
vertical
divisions
vertical
spacing
129
Tile - Glide
Reected
rectangular tile effect angle width x position y position
Combined Effects continued...
