PRG Mbox - Page 220

210
MBOX® USER MANUAL
Value Effect Description Mod 1 Mod 2 Mod 3 Mod 4 Mod 5
130
Tile - 4-fold
Rotated
four-sided tile effect angle
acute
angle
width x position y position
131
Tile - 4-fold
Reected
four-sided tile effect angle
acute
angle
width x position y position
132
Tile - 4-fold
Translated
four-sided tile effect angle width x position y position
133
Tile - 6-fold
Rotated
six-sided tile effect angle width x position y position
134
Tile - 6-fold
Reected
six-sided tile effect angle width x position y position
135
Tile - 8-fold
Reected
eight-sided tile effect angle width x position y position
136
Tile - 12-fold
Reected
twelve-sided tile effect angle width x position y position
137 Tile - Parallelogram parallelogram tile effect angle
acute
angle
width x position y position
138 Tile - Triangle triangular tile effect angle width x position y position
139-
143
Reserved
144 Screen - Line
line patterned halftone
screen
width angle sharpness
145 Screen - Circular
line patterned halftone
screen
width sharpness x position y position
146 Screen - Dot
line patterned halftone
screen
width angle sharpness
147 Screen - Hatched
line patterned halftone
screen
width angle sharpness
148
Screen - CMYK
Halftone
color, halftone rendition width angle sharpness GCR UCR
149-
152
Reserved
153 Decay creates decay trails mixer amount
154 Black & White
converts image to
transparent/color
mixer threshold red green blue
155 Mirrors various mirror modes mixer mode
156 Horizontal Bars break image into bars mixer number width
157 Vertical Bars break image into bars mixer number width
158 Double Vision offset image and overlay mixer x offset y offset
159 Rippling simple ripple effect mixer size granularity
160 Flicker dynamic ickering effect mixer size speed
161 Shake 2D dynamic shaking effect mixer size speed
Combined Effects continued...
