OIT Jog Control
(PVA250™, PVA750™, PVA2000C™ models only)
OIT Jog Control allows the operator to jog the gantry via the OIT function keys to perform teach functions.
[F1] EXIT
– Leave OIT Jog Control and return to the previous mode.
[F2] TEACH
– Program the current point.
[F3] PURG
– Actuate the current valve.
[F4] AXIS
– Toggle axis control between X, Y and Z.
[F5] -Y
– Jog the Y axis in the negative direction.
[F6] -X
– Jog the X axis in the negative direction.
[F7] +X
– Jog the X axis in the positive direction.
[F8] +Y
– Jog the Y axis in the positive direction.
To jog an axis, press and hold the function key that corresponds to the axis and direction of motion desired.
Once the axis is in motion for approx. 1 sec, the speed will increase by a factor of 15.
F7F
6
F
5
F4
F
3
F2
F1
Jo
g
Mode
EXIT Teach PRG AXIS -Y -X +X +Y
