PVA PVA2000 - Computer 9 Pin to Workcell Programming Port; Computer 25 Pin to Workcell Programming Port; Table 11 - Cable for Computer DB9 to Workcell; Table 12 - Cable for Computer DB25 to Workcell

Operation and Maintenance Manual Rev M(ii) 4/03
- 55 -
13 Secondary CTS
14 Secondary TD
15 DCE Transmitter Clock
16 Secondary RD
17 Receiver Signal Clock
18 Unused
19 Secondary RTS
20 Data Terminal Ready (DTR)
21 Signal Quality Detector
22 Ring Indicator (RI)
23 Data Signal Rate Selector
24 DTE Transmitter Clock
25 Unused
Computer 9 Pin to workcell Programming Port
For standard communication between a computer and a workcell.
Table 11 – Cable for Computer DB9 to workcell
Comp
DTE
DB9
workcell
DCE
DM9F
1 1
2 2
3 3
4 4
5 5
Computer 25 Pin to workcell Programming Port
For standard communication between a computer and a workcell.
Table 12 – Cable for Computer DB25 to workcell
Comp
DTE
DB9
workcell
DCE
DM9F
1 5
2 3
3 2
4 1
5 4
