Operation and Maintenance Manual Rev M(ii) 4/03
- 32 -
[F5] -Y – Jog the Y axis in the negative direction.
[F6] -X – Jog the X axis in the negative direction.
[F7] +X
– Jog the X axis in the positive direction.
[F8] +Y
– Jog the Y axis in the positive direction.
To jog an axis, press and hold the function key that corresponds to the axis and direction of motion desired.
Once the axis is in motion for approx. 1 sec, the speed will increase by a factor of 15.
